S5 Solar Panel aims to help reduce the effects of climate change and sustainability for future generations with easy, fast and energy efficient building solutions. It makes a difference with the advantage of being produced both in Balıkesir and İskenderun.
S5 SOLAR PANEL
- With the special clamp system of S5 Solar Panel, solar panels can be mounted directly without drilling the sandwich panel surface.
- Corrosion and waterproofing risks caused by screw holes in buildings are eliminated, thus protecting the structural integrity of the roofs and extending the life of the building.
- With a guarantee of up to 20 years, S5 Solar Panel provides unmatched heat efficiency and energy savings, as well as superior fire protection.
- It offers a 100% sustainable alternative for buildings with its advanced daylight lighting and integrated roof solar energy system.
- Thanks to its special pitch system, it has a structure compatible with photovoltaic modules of all sizes.
- It has the advantage of production in its İskenderun location.
- Fast assembly can be done thanks to the lateral overlapping panel combination.
- Capped system combination can be made optionally.
Product Information
Production Plant
Balıkesir & İskenderun
Favourable Width
1000 mm
Minimum Length
3 meters
Maximum Length
Depends on Transport Conditions
Density (EN 1602)
SmartCore&PIR Elite: 41(±2) kg/m3 – PIR: 40(±2) kg/m3
Thickness
40-50-60-70-80-100 mm
Thermal Conductivity λ (EN 13165)
SmartCore: 0,018 W/m K – PIR&PIR Elite: 0,022-0,024 W/m K
Dimensional Stability (EN 13165)
Level DS (TH) 11
Reaction to Fire (EN 13501)
PIR Elite: B-s1,d0 – PIR: B-s2,d0
Water Absorption (EN ISO 354)
By Volume %2 (168 hours)
Closed Cell Percentage (EN 14509)
%95
Vapour Diffusion Resistance (EN 12086)
30-100
Heat Resistance
-200 /+110 ºC
