It is a three-indented lateral connected sandwich panel which is produced as pre-painted galvanize steel on top, with GRP on the bottom surface. Roofs with a 10% gradient can be covered. GRP panels are used in the facilities specifically in poultry farms where hygienic requirements are prioritized. Furthermore, it is a product that is mostly used for the facilities which has corrosion risk and for the projects requiring low budget solutions where a mechanical performance is not highly required. In order to facilitate the assembly of the product, tapes can be applied to the GRP part which is left long.
N3 GRP ROOF PANEL
- It is a 3-pitch lateral connected sandwich panel produced as pre-painted galvanized metal on top, with GRP on the bottom surface.
- Applicable to roofs with a 10% gradient.
- Mostly used in facilities with a corrosion risk and in projects requiring for cost-efficient solutions where a mechanical performance is not highly required.
- In order to facilitate the assembly of the product, bands can be applied to the GRP part which allows for an excess margin.
Product Information
Production Plant
İskenderun
Favourable Width
1000 mm
Minimum Length
3 meters
Maximum Length
9 meters
Metal Type
Pre-painted Galvanized Sheet
External Metal Thickness
0.50 mm
Thickness Tolerance
Nominal
Sheet Metal Quality
Dx51 D+Z Prepainted Galvanized Sheet Metal (polyester paint finish on primer)
Hot Dipped Coated Quantity
100-275 gr/m2
Paint Type
Polyester, PvdF, Plastisol, PVC
