Provides excellent integrity between concrete and steel with 53 mm pitch height and advanced form features. Wide gaps can be spanned easily where the load capacity is at a maximum with this special feature corrugated sheet. The lateral embossments raised on the pitches in opposite directions provide high performance adherence between steel and hardened concrete. The modular width of the 53/333 Deck Corrugated Sheet is 1,000 mm. The wide and effective coating area is economical in both material and labor. 53/333 Deck Corrugated Sheet is produced as roll-form. The 16m maximum production length of Deck Corrugated Sheet can be produced in thicknesses from 0.70 mm to 1.50 mm.
53/333 DECK CORRUGATED SHEET
- Due to its special form, it can cover wide gaps.
- it can cover wide gaps as it can be manufactured by thickness up to t: 1.50 mm.
- It can be manufactured as galvanized sheet or painted galvanized sheet so it offers an aesthetic appearance.
- As its useful width is 1,000 mm, it offers great cost-efficiency both for material and labor.
- It can be used as permanent form.
- It can be used with lightweight and common concrete.
- It offers extra integrity thanks to its corrugated form.
- It reinforces the supporting frame in case of using steel frame in the system.
- It offers extra tensile strength.
- It allows for an easy, fast, and practical installation.
Product Information
Production Plant
İstanbul
Favourable Width
1000 mm
Minimum Length
1 meters
Maximum Length
Depends on transport conditions.
Metal Type
Galvanized Steel
Sheet Thickness
0,80-1,50 mm
Steel Surface Yield Strength
min. 220 N/mm2
Thickness Tolerance (EN 10143)
Nominal
Length Tolerance
±3 mm
Steel Quality (EN 10327)
DX51 D+Z Boyalı Galvanizli Sac
Hot Dipped Coated Steel Grade (EN 10327)
100-275 gr/m2
