The single layer corrugated steel manufactured from galvanize or aluminum in 18/76 form. Applicable to both roofs and walls. Has sinus grooves and 838 mm net application width.
18-76 СИНУС
- Color options are available in RAL catalogue.
- Finishing (Polyester, PvdF, Plastisol, PVC) options are available for application site.
- It can be used as cladding in high slope roof and wall applications.
Информация о товаре
Production Plant
İstanbul-İskenderun
Favourable Width
838 mm. (Tolerance: ±3 mm)
Length
Min. 1meters -Max.12 meters
Application
Roof and Wall
Metal Specifications
Assan Aluminum production. High Conditioned AW 3000 series aluminum. Galvanized Sheet, Finished Galvanized Sheet (polyester finish on primer)
Metal Thickness
Min.0.50 mm.-Max.0.80 mm. Finished Galvanized Sheet/Galvanized Sheet Min.0.40 mm.-Max.0.80 mm. Aluminum
